Fibre inputs 1 x FC/PC
Input range 1100..1650 nm / - 15 .. - 10 dBm
RF frequency range 85 .. 6200 MHz
Terrestrial range 85 .. 862 MHz
Num of Ubs 1 x 16
Output level CSS (AGC) 77 dBmV
Max load @ 5 V (terr. only) 90 mA
Max load @ 14 V (16 UBs) 290 mA
Dimensions [mm3] 91 x 72 x 23
Screening / EMC CE, Class A
